2200r/Min 10t Logistics Machinery 4 Wheel Electric Forklift

2200r/Min 10t Logistics Machinery 4 Wheel Electric Forklift
2200r/Min 10t Logistics Machinery 4 Wheel Electric Forklift

Large Image :  2200r/Min 10t Logistics Machinery 4 Wheel Electric Forklift

Product Details:
Place of Origin: China
Brand Name: XDEM
Certification: ISO CE
Model Number: CPCD100
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD8000-12000
Packaging Details: Nude packing
Delivery Time: 30 working days
Payment Terms: L/C, T/T
Supply Ability: 500 sets per month
Detailed Product Description
Condition: New Power Type: Diesel
Capacity: 10000kg Load Center: 600mm
Wheel Base: 2800mm Lifting Height: 3000m
Forks Size: 1220×175×80
High Light:

2200r/min Logistics Machinery

,

10t 4 wheel electric forklift

,

10t Logistics Machinery

YTO Forklift 10ton Diesel Forklift Truck stacker manual Prices For Forklifts CPCD100

XDEM Forklift 10ton Diesel New Forklift Truck CPCD100



1. Reliable engine
Our hydraulic internal combustion forklift truck uses high quality diesel engine, which can offer strong power.
2. Intelligent driving control system
It is equipped with digital intelligent driving control system, so the operation data of forklift can be obtained and the whole process control can be achieved.
3. Full hydraulic flexible steering system
Its full hydraulic steering system can help ease the fatigue of operator. The steering system is designed with crank sliding piece steering mechanism, so the reliable steering can be guaranteed.
4. Classical space frame structure
Our hydraulic internal combustion forklift truck uses classical ASF YTO space frame structure. It is ergonomically designed, aesthetic in appearance, compact in structure, and easy to operate.
5. Good scope of eyesight
The construction equipment adopts optimized gantry rail section design and the enlarged internal width enables the driver to enjoy a wide scope of eyesight.

Speciality parameter Model     CPCD100
Power type     Diesel
Rated capacity   kg 10000
Load center d mm 600
Lift height h2 mm 3000
Mast tilt angle (forward/backward) α/β Deg 6/12
Front overhang L3 mm 710
Wheel-base L4 mm 2800
Tread(front/rear) b4/b5 mm 1600/1720
Performance parameter Travel brake     Hydraulic-Foot pedal
Parking brake     Mechanical-Hand level
Lift speed(with/without load)   mm/s 310/340
Lower speed (with/without load)   mm/s with load300
Travel speed (with/without load)   km/h 23/26
Max. gradeability (with load)   % 20
Max. Towing (with/without load)   kN 50/40
Weight Distribution with load(pront/rear)     20470/2030
Weight Distribution without load(pront/rear)     6000/6500
Power, transmission and others Engine Model     LR6B5-22
Manufacturer     YTO
Rated power   kw 88.2/2200
Max.roration     440/1600
Dispilacement     7.42
Battery Voltage   V 24
Capacity   Ah 2×100
Gearbox Transmission type     Hydraulic
Gears,speed (front/rear)     Ⅱ/Ⅱ
Tire type     Pneumatic tyre
Model Pront     9.00-20-14PR
Rear     9.00-20-14PR
Other Self.weight   kg 12500
Free lift height h4 mm 165
Fork Thickness×Width×Length c×b×a mm 80×175×1220
Overall dimensions Overall length(without forks) L2 mm 4240
Overall width b1 mm 2165
Overall height Extended height(mast) h1 mm 4330
Lower height(mast) h3 mm 2850
Overhead guard h7 mm 2575
Min. turning radius Wa mm 3950
Min. under ground
clearance
Under mast m1 mm 245
Center of wheel-base m2 mm 255
