YTO X1004 100hp Agriculture Farm Tractor With 6 Cylinder Engine

Certification
China Nanyang Xinda Electro-Mechanical Co., Ltd. certification
China Nanyang Xinda Electro-Mechanical Co., Ltd. certification
I'm Online Chat Now

YTO X1004 100hp Agriculture Farm Tractor With 6 Cylinder Engine

YTO X1004 100hp Agriculture Farm Tractor With 6 Cylinder Engine
YTO X1004 100hp Agriculture Farm Tractor With 6 Cylinder Engine YTO X1004 100hp Agriculture Farm Tractor With 6 Cylinder Engine YTO X1004 100hp Agriculture Farm Tractor With 6 Cylinder Engine YTO X1004 100hp Agriculture Farm Tractor With 6 Cylinder Engine YTO X1004 100hp Agriculture Farm Tractor With 6 Cylinder Engine

Large Image :  YTO X1004 100hp Agriculture Farm Tractor With 6 Cylinder Engine

Product Details:
Place of Origin: China
Brand Name: YTO
Certification: ISO
Model Number: X1004
Payment & Shipping Terms:
Minimum Order Quantity: 1 unit
Price: USD21500
Delivery Time: 30 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 200 UNIT PER month
Detailed Product Description
Power: 100hp Size: 5010×2192×2865
Engine: 6-cylinder, Vertical, Water-cooled, 4-stroke, Direct Injection Diesel Engine By Wheel: 4WD
Usage: Farm Tractor Color: Red
High Light:

100hp agriculture farm tractor

,

yto x1004 agriculture farm tractor

,

100hp 4wd lawn tractor

YTO 100hp Tractor X1004 100HP agriculture farm tractor YTO tractor Good quality high working efficiency





The Introduction of YTO 100HP X1004 Tractor Agricultural Tractor 4WD Tractor for sale

YTO- LX1004/LX1104/LX1204/LX1254/LX1304 wheeled tractors are the 4WD tractors of international leading standards developed by YTO GROUP CORPORATION on our own based on advanced international technology and market demands.
It has powerful engine with extraordinary performance, beautiful outlook, wide scope of sight, good adaptability, extensively used in field operation and transport work.
Main features:
Hi-powered engine, low fuel consumption, good power/fuel economy.
T/M is basically configured with 12+4 gears, multiple no. of gears, optional with creeper gear, wide selection of speeds, easy to operate, efficient, uses chassis radiation system to satisfy the heavy loading conditions.
Closed cab, perfect styling, wide scope of sight, good riding comfort. Can be optioned with A/C, heater, CD player and etc.
Tractors are of big traction force and can be used in factories, warehouses, airports, dwarfs to trail the vehicles as well as transport application.
Differential lock uses lock-latch differential, reliable and easy to use.
Hydraulic steering, mechanical braking, easy and flexible to operate, so as to reduce the fatigue of operators.
Independent PTO can satisfy the rotary tilling, harvesting, sowing, fertilizer spreading and rice milling operations and etc; with synchronous PTO output functions.
Reliable hydraulic lifting system features oil dividing mechanism good to use. Big lifting force, with multi-tilling depth controls of position adjustment and draft control, tractors work with heavy duty and combined implements, forced soil-intrusion implements can be optional.
2 sets of hydraulic output and 3-set are optional, hydraulic system has oil return filtering system, little pollution.
Main data:



The Parameter of YTO 100HP X1004 Tractor Agricultural Tractor 4WD Tractor for sale



Models YTO-X1004
Type 4×4
Overall dimension(mm) 5010×2192×2865
Front wheel base adjustable (mm) 1672~2003
Rear wheel base adjustable(mm) 1600~2200
Min ground clearance(mm) 450
Min turning radius (m) 6.5±0.2
4750
No. of gears, forward/reverse 12F+4R
Range of speed forward(km/h) 2.06~28.4
reverse(km/h) 4.45~13.28
Engine Model LR6A3-23
Type

6-cylinder, vertical,

water-cooled, 4-stroke,

direct injection diesel engine

Rated power (kW) 73.5
Rated revolution (r/min) 2300
Fuel consumption rate under rated working conditions(g/kW.h) ≤242
TIRE SIZE FRONT

14.9-24/12.4—26

(paddy rice wheels)

REAR

16.9-38/18.4—34

(sugar cane field wheels)

Max lifting force at point of 610mm behind the hitch (kN) ≥24
PTO

rear, independent &

synchronized

PTO revolution speed (r/min)

540(6-spline)/1000

(21-spline), options:

540(6-spline)/720(8-spline),

540(6-spline) 720(8-spline)

1000(21-spline





YTO X1004 100hp Agriculture Farm Tractor With 6 Cylinder Engine 0YTO X1004 100hp Agriculture Farm Tractor With 6 Cylinder Engine 1YTO X1004 100hp Agriculture Farm Tractor With 6 Cylinder Engine 2YTO X1004 100hp Agriculture Farm Tractor With 6 Cylinder Engine 3
