380V Solid Tire Press Machine , 200T Tire Change Machine

380V Solid Tire Press Machine , 200T Tire Change Machine
380V Solid Tire Press Machine , 200T Tire Change Machine 380V Solid Tire Press Machine , 200T Tire Change Machine 380V Solid Tire Press Machine , 200T Tire Change Machine 380V Solid Tire Press Machine , 200T Tire Change Machine 380V Solid Tire Press Machine , 200T Tire Change Machine 380V Solid Tire Press Machine , 200T Tire Change Machine

Large Image :  380V Solid Tire Press Machine , 200T Tire Change Machine

Product Details:
Place of Origin: China
Brand Name: XDEM
Model Number: YM200T
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD4000-6000
Packaging Details: export package
Delivery Time: 10 working days
Payment Terms: L/C, T/T, Western Union, MoneyGram, D/P, D/A
Supply Ability: 1000 sets per month
Detailed Product Description
Power Source: Hydraulic Voltage: 380V
Weight: 3550kg Nominal Force: 200T
Cylinder Diameter: 500 Motor Power: 7.5kW
Weight (KG): 5000 Machine Type: Hydraulic Press
High Light:

200T solid tire press machine

,

200t tire change machine

,

380V solid tire press machine

XDEM 200T Hydraulic Solid Tire Press 23.5-25/32.5-35 Solid Tire Change Machine Forklift Solid Tires 100T 120T 160T



XDEM 200T Hydraulic Solid Tyre Press/Changer



Hydraulic solid tire press is a tire disassembly device used to disassemble rims and tires with retaining rings. 100T/120T/160T/200t produced by our company can be used to disassembly solid tires, engineering tires, loader tires, forklift tires, agricultural tires, rims, wheels, steel rings, industrial tires, etc.



When using, firstly select the tooling correctly, then place the wheel hub on the workbench, press the tool head on the tire into the wheel hub, and finally load the snap ring with the guide ring.



Different types of tires and wheels require different tooling. Users should choose tooling before disassembling the tires. This will be very convenient and quick.



380V Solid Tire Press Machine , 200T Tire Change Machine 0





Main Parameters

1 Model / YM200T
2 Nominal force KN 2000
3 Stroke mm 600
4 Opening mm 1600
5 Worktable effective area mm 1800*2600
6 Worktable lateral stroke mm 1000
7 Worktable height above ground mm 550
8 Side cylinder nomial pressure KN 100
9 Motor KW 7.5
10 Oil pump YCY 40
