HZS180 205KW 180m3/H Mobile Concrete Batching Plant Road Construction Machinery

HZS180 205KW 180m3/H Mobile Concrete Batching Plant Road Construction Machinery
HZS180 205KW 180m3/H Mobile Concrete Batching Plant Road Construction Machinery HZS180 205KW 180m3/H Mobile Concrete Batching Plant Road Construction Machinery HZS180 205KW 180m3/H Mobile Concrete Batching Plant Road Construction Machinery HZS180 205KW 180m3/H Mobile Concrete Batching Plant Road Construction Machinery

Large Image :  HZS180 205KW 180m3/H Mobile Concrete Batching Plant Road Construction Machinery

Product Details:
Place of Origin: China
Brand Name: XDEM
Certification: CE ISO
Model Number: HSZ180
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD80000-100000
Packaging Details: Nude
Delivery Time: 45 working days
Supply Ability: 500 sets per month
Detailed Product Description
Type: HZS180 Productivity In Theory: 180m³/h
Mixer: JS3000 Total Power: 205KW
High Light:

180m3/h Mobile Concrete Batching Plant

,

180m3/h automatic batching plant

,

205KW automatic batching plant

XDEM HZS180 180m3 per hour Mobile Concrete Batching Plant

Concrete Batching Plant HZS180

HZS series Concrete Mixing Plants, also named as batching plants, is designed by our company and has advanced technology in the world. It is suitable for the commodity concrete and concrete construction in each kind of architectural project, including the water conservancy , the electric power , the railroad, the road ,the tunnel and other various concrete.This HZS series use JS series double shaft compulsory mixer.



Main features of HZS180 Concrete Batching Plants :

1,Adopt the most advanced technologies all over the world.

2.Aggregate batching system adopts PLD4800 concrete batcher which offers efficient and accurate measurement.

3.Mixing and aggregate lifting system adopt JS3000 double-shaft compulsory concrete mixer which offers efficient and high quality mixing.

4.Reasonable,design of mixer, short mixing time,lower consumption,little noise, and the wearing parts has long life.

5.The discharge gate uses the pneumatic control.There are three stopover and it has the manual switch.



Main Technical Parameters of HZS180 Concrete Batching Plants :



Main technical data
Type HZS180
Productivity in theory 180m³/h
Mixer JS3000
Total power 205KW
Maximum aggregate diameter 80mm
Aggregate feeding method Conveyor belt
Aggregate bins volume 4x18m³
Aggregate weighing 2x4000kg ±2%
Cement weighing 1800kg ±1%
Fly-ash weighing 800kg ±1%
Water weighing 800kg ±1%
Additive weighing 50kg ±1%
Discharging height 3.8m

Overall dimension(during operating)

(LXWXH)

58.5mX7mX12.9m
Total weight 77T
Control Fully automatic central control
