Lithium Battery Forklift 1.5ton 1.6ton 2ton 2.5ton 3ton 3.5t Hydraulic Electric Forklift

Certification
China Nanyang Xinda Electro-Mechanical Co., Ltd. certification
China Nanyang Xinda Electro-Mechanical Co., Ltd. certification
I'm Online Chat Now

Lithium Battery Forklift 1.5ton 1.6ton 2ton 2.5ton 3ton 3.5t Hydraulic Electric Forklift

Lithium Battery Forklift 1.5ton 1.6ton 2ton 2.5ton 3ton 3.5t Hydraulic Electric Forklift
Lithium Battery Forklift 1.5ton 1.6ton 2ton 2.5ton 3ton 3.5t Hydraulic Electric Forklift

Large Image :  Lithium Battery Forklift 1.5ton 1.6ton 2ton 2.5ton 3ton 3.5t Hydraulic Electric Forklift

Product Details:
Place of Origin: China
Brand Name: XDEM
Certification: CE
Model Number: CPD25
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD16900/set
Packaging Details: Nude packing
Delivery Time: 30 working days
Supply Ability: 100 sets per month
Detailed Product Description
Model: CPD25 Motor: AC/DC
Mast: 3m Duplex Mast Tire: Pneumatic
Color: Red, White, Yellow, Etc.. Warranty: One Year Or 2000 Working Hours
Load Center: 500mm
Highlight:

1.5ton lithium battery forklift

,

2ton lithium battery forklift

,

3ton lithium battery forklift

Lithium Battery Forklift 1.5ton 1.6ton 2ton 2.5ton 3ton 3.5t Hydraulic Electric Forklift 0

lithium battery forklift 1.5ton 1.6ton 2ton 2.5ton 3ton 3.5t hydraulic electric forklift

Model: CPD
Loading capacity: 1500kg / 2000kg / 3000kg / 4000kg
Load center: 500mm
Lifting height: 3000-6000mm

Lithium Battery Forklift 1.5ton 1.6ton 2ton 2.5ton 3ton 3.5t Hydraulic Electric Forklift 1



1) China top brand lithium battery, 80V/150Ah, 80V/202Ah, 80V/280Ah, 80V/404Ah, water automatic filling system is poptional.
2) Mast optional: 3/4m duplex mast, 3.6/4/4.5/5/5.5/6m triplex mast, 3/3.3/3.5/4/m duplex full free mast.
3) Transmission: Automatic/manual;
4) Tire: pneumatic/Solid/non-mark solid;
5) Forks: 1070/1220/1370/1520/1670/1820/1970mm;
6) Attachments: Side shifter, fork positoner, fork sleeve, paper roller clamp, bale clamp, drum clamp, load extender, rotator,
fork clamps, push/pull, etc..
7) Additional: Cabin, heating, fan, air conditioner, high exhaust, paper fold, USB, camera & image, suspension seat, etc.


Lithium Battery Forklift 1.5ton 1.6ton 2ton 2.5ton 3ton 3.5t Hydraulic Electric Forklift 2
Wide view
The compact structure of standard wide view frame and hose pulley block makes the operator a better view.
Reinforced components
The maintenance-free wet disc brake system provides excellent brake performance. The compact structure, small deflection, and
dust-proof and water-proof design of the casting steering axle endow the forklift with long service life and working reliability.
Lithium Battery Forklift 1.5ton 1.6ton 2ton 2.5ton 3ton 3.5t Hydraulic Electric Forklift 3

Advanced AC motor

Compared with DC motor, the maximum speed of AC motor is higher, which is more compact yet more powerful. With faster start-up
response, the forklift can run at full speed over short dis-tances. No need to replace the carbon brush or diverter, thus saving
maintenance cost.
Lithium Battery Forklift 1.5ton 1.6ton 2ton 2.5ton 3ton 3.5t Hydraulic Electric Forklift 4

High quality lead-acid battery

Cost-effective lead-acid battery is adopted, which has the characteristics of high-rate discharge performance, no ignitability,
large temperature window, zero pollution, high recycling rate, and long service life.
Lithium Battery Forklift 1.5ton 1.6ton 2ton 2.5ton 3ton 3.5t Hydraulic Electric Forklift 5



Low voltage DC charger

Corresponding low voltage DC charger is provided based on the power of lead-acid battery. Equipped with China national standard
charging gun,butt converter of different specifications are optionally provided to meet various charging specifications.
Lithium Battery Forklift 1.5ton 1.6ton 2ton 2.5ton 3ton 3.5t Hydraulic Electric Forklift 6

Lithium Battery Forklift 1.5ton 1.6ton 2ton 2.5ton 3ton 3.5t Hydraulic Electric Forklift 7

Characteristics
Manufacturer


XDEM
Model


CPD20
CPD25
Rated capacity
Q
kg
2000
1500
Load center distance
C
mm
500
500
Power type


Lithium Battery
Lithium Battery
Driving type


Seated
Seated
Wheel base
L1
mm
1500
1500
Tyres
Tyre type


Pneumatic
Pneumatic
Wheel number(front/rear)


2X/2
2X/2
Front tread
W3
mm
970
970
Rear tread
W2
mm
950
950
Tyre(front)


7.00-12-12PR
7.00-12-12PR
Tyre(rear)


18X7-8PR
18X7-8PR
Size
Front overhang
L2
mm
468
468
Mast tilting angle,front/rear
α/β
°
6/12
6/12
Height with mast retraction
H1
mm
1995
1995
Free lifting height
H3
mm
150
150
Max. lifting height
H
mm
3000
3000
Max. height after lifting
H2
mm
4045
4045
Overall guard height
H4
mm
2098
2098
Fork size: length x width x thickness
LxWxT
mm
1070x100x40
1070x120x40
Overall length(fork excluded)
L'
mm
2353
2353
Overall width
W1
mm
1170
1170
Turning radius
r
mm
2172
2172
Ground clearance of mast
H5
mm
110
110
Ground clearance of wheel base center(loaded)
H6
mm
105
105
Right angle stacking aisle width
(pallet 1000x1000mm,clearance 200mm)
Ast
mm
4040
4040
Right angle stacking aisle width
(pallet 1200x1200mm,clearance 200mm)
Ast
mm
4240
4240
Lateral fork adjustment
Max./Min.
W5
mm
1038/200
1038/240
Performance
Travelling speed (loaded/unloaded)

km/h
12/14
12/14
Lifting speed (loaded/unloaded)

mm/s
320/450
320/450
Lowering speed

mm/s
<600
<600
Gradeability (loaded)

%
12
12
Weight
Total weight

Kg
4214
4270
Battery
Battery voltage /capacity

V/Ah
80/202
80/230
Lithium Battery weight

Kg
715
750
Motor and controller
Driving motor power-60 minutes

Kw
11
11
Lifting motor power(S3 15%)

Kw
12
12
Driving motor control mode


AC
AC
Lifting motor control mode


AC
AC
Service brake/parking brake


Hydraulic /Mechanical
Hydraulic /Mechanical
Hydraulic system working pressure

Mpa
17.5
17.5
Note: (1)Detailed information about battery,please contact our salesmen or engineer.
