Q355B High Quality Excavator Bucket Standard Purpose Type Bucket General Purpose 1.5m3 Bucket For 35Ton Excavators

All Products
Agriculture Farm Tractor (46)
Farm Tractor Attachments (22)
Tractor Engine Parts (15)
Portable Line Boring Machine (45)
Steel Structure Engineering (9)
Earth Excavation Machine (51)
Well Drilling Machine (28)
Logistics Machinery (31)
High Temperature Furnace (35)
Road Construction Machinery (98)
Special Vehicles (44)
Lightning Surge Arrester (20)
Silk Textile (138)
Organic Fertilizer Equipment (42)
Coffee Roaster (25)
Three Wheel Motorcycle (3)
Certification
China Nanyang Xinda Electro-Mechanical Co., Ltd. certification
China Nanyang Xinda Electro-Mechanical Co., Ltd. certification
I'm Online Chat Now

Q355B High Quality Excavator Bucket Standard Purpose Type Bucket General Purpose 1.5m3 Bucket For 35Ton Excavators

Q355B High Quality Excavator Bucket Standard Purpose Type Bucket General Purpose 1.5m3 Bucket For 35Ton Excavators
Q355B High Quality Excavator Bucket Standard Purpose Type Bucket General Purpose 1.5m3 Bucket For 35Ton Excavators

Large Image :  Q355B High Quality Excavator Bucket Standard Purpose Type Bucket General Purpose 1.5m3 Bucket For 35Ton Excavators

Product Details:
Place of Origin: China
Brand Name: XDEM
Certification: ISO CE
Model Number: Komatsu/CAT
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD5000-10000
Packaging Details: Nude packing
Delivery Time: 15 working days
Supply Ability: 10sets per month
Contact Now
Detailed Product Description
Application: Machinery Repair Shops Condition: New
Weight: 2000kg Color: Yellow Or Orange
Process: Forging /casting Material: 42Mn2
Surface Hardness: HRC52-58 Hardness Depth: 8-12mm
Type: Excavator Part
Highlight:

1.5m3 Excavator Bucket

,

High Quality Excavator Bucket

,

35Ton Excavator Bucket

Excavator Hydraulic Tilt Bucket
XDEM Excavator Tilt Buckets are designed for ditch cleaning and sloping grading. Our tilting bucket can tilt 45 degrees in either side to increase productivity. And our tilting bucket also designed with double cylinders and with double cutting edges(Single cylinder design is also available). The space of bolts in cutting edges are 6 inch, which is the standard cutting edges for you can find spare cutting edges in local easily. All hoses are arranged well, the only thing you need to do is to install our tilting bucket with your spare hoses in excavator.

Q355B High Quality Excavator Bucket Standard Purpose Type Bucket General Purpose 1.5m3 Bucket For 35Ton Excavators 0
Q355B High Quality Excavator Bucket Standard Purpose Type Bucket General Purpose 1.5m3 Bucket For 35Ton Excavators 1



Quality Certification of Steel, Q355B Steel for Structure:
We adopted qualified Q355B steel from top 3 Chinese steel maker. Q355B is the most common used material in the industrial, same as European S355JR, American A57.etc.
Moreover, we also offer options using high strength material such as:NM400, Hardox500 and HG785D.
All steels are adopted from CSG, top 3 steel maker in China.
Material
Code
Hardness(HB)
Extension(%)
Bend Intensity
Alloy Steel
Q355B
163-187
21
355(N/mm2)
Chinese High-Strength alloy
NM400
400
16
1020(N/mm2)
High-Strength alloy
HARDOX-500
470-500
8
1300(N/mm2)
Q355B High Quality Excavator Bucket Standard Purpose Type Bucket General Purpose 1.5m3 Bucket For 35Ton Excavators 2
Q355B High Quality Excavator Bucket Standard Purpose Type Bucket General Purpose 1.5m3 Bucket For 35Ton Excavators 3

Reference General Arrangement Drawing

We will make the General Arrangement Drawing according to your needs. In order to ensure the perfect size, all products will be produced after you confirm the final drawing.
Q355B High Quality Excavator Bucket Standard Purpose Type Bucket General Purpose 1.5m3 Bucket For 35Ton Excavators 4

How to choose?

What is your excavator model?
Which type do you want?
The arm width, pin diameter and pin center to center.
Q355B High Quality Excavator Bucket Standard Purpose Type Bucket General Purpose 1.5m3 Bucket For 35Ton Excavators 5
Q355B High Quality Excavator Bucket Standard Purpose Type Bucket General Purpose 1.5m3 Bucket For 35Ton Excavators 6
Q355B High Quality Excavator Bucket Standard Purpose Type Bucket General Purpose 1.5m3 Bucket For 35Ton Excavators 7
Q355B High Quality Excavator Bucket Standard Purpose Type Bucket General Purpose 1.5m3 Bucket For 35Ton Excavators 8
Q355B High Quality Excavator Bucket Standard Purpose Type Bucket General Purpose 1.5m3 Bucket For 35Ton Excavators 9
