XDEM Brake Drum Refaceing Machine Brake Drum Boring Machine T8370 Track Pin Press Auto Repair Shop

XDEM Brake Drum Refaceing Machine Brake Drum Boring Machine T8370 Track Pin Press Auto Repair Shop
XDEM Brake Drum Refaceing Machine Brake Drum Boring Machine T8370 Track Pin Press Auto Repair Shop

Large Image :  XDEM Brake Drum Refaceing Machine Brake Drum Boring Machine T8370 Track Pin Press Auto Repair Shop

Product Details:
Place of Origin: China
Brand Name: XDEM
Model Number: T8370
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD4000-6000
Packaging Details: export package
Delivery Time: 10 working days
Payment Terms: L/C, T/T, Western Union, MoneyGram, D/P, D/A
Supply Ability: 1000 sets per month
Contact Now
Detailed Product Description
Model: T8370 Processing Range: 180-700mm
Spindle Speed: 0-100rpm Spindle Motor: 3kW
Lift Motor: 1.1kW

XDEM Brake Drum Boring Machine T8370



It is special for brake drum of large truck/lorry/bus, optional for brake shoe & hubless brake drum.
Whole column design enables, better rigidity than old structure.
Super strong spindle structure, makes boring elliptical deformable/surface hardened brake drum available.

Features:
1. High rigidity. It is integrated with transmission system & stand, so the rigidity is strengthened.
2. Wide machining range. This model is with very big machining diameter among all the brake drum boring machines in china.
3.Perfect operation system. The quick up/down & positive/negative feed increases the working efficiency and the integrated button station achieves convenient operation.
4.Applicable for widel car types. It can machine not only brake drums & brake shoes.
Main paramers:
Model
T8370
Range of Processing Diameter mm
180-700
Rotating Speed of Workpiece r/min
24 / 45 / 80
Working Travel of Slideboard mm
400
Lift Motor Power kW
1.1
Spindle Motor Power kW
3
Weight kg
800
Overall Dimensions mm(L x W x H)
1200 x 1000 x 1815

XDEM Brake Drum Refaceing Machine Brake Drum Boring Machine T8370 Track Pin Press Auto Repair Shop 0XDEM Brake Drum Refaceing Machine Brake Drum Boring Machine T8370 Track Pin Press Auto Repair Shop 1

XDEM Brake Drum Refaceing Machine Brake Drum Boring Machine T8370 Track Pin Press Auto Repair Shop 2

Tag:

Portable Line Boring Equipment,

AC220V hydraulic pin press,

AC220V Portable Line Boring Machine
